testo 330-2 LL Set 2

Thanks to the new instrument functions, the Testo flue gas analyzers of the new testo 330-LL series now offer you even more professional and reliable support. These are the main features: • High-resolution colour display for the graphic representation of your measurement data • Extended measurement menus – such as gas pipe testing – for a comprehensive analysis of your heating system • Logger function for easy long-term recording of the measurement curve

• Graphic processing of measurement data• Instrument diagnosis function uses easy „traffic light’’ presentation to enable comprehensive instrument diagnosis• Pressure measurement up to 300 mbar• User-defined fuels• TÜV-tested according to 1. BImSchV / EN 50379 Part 2 for O2, °C, hPa and CO with H2-compensation• Powerful memory management: 500,000 readings• IrDa/ Bluetooth interface for data transfer to Pocket-PC / laptop / printer• USB interface for data readout to a PC software• ZIV (Central Guild Association) driver for all standard industry software packages• In CO measurement, from 8.000 ppm, automatic dilution is carried out up to min. 30,000 ppm CO• Integrated gas and draught zeroing without probe removal: The probe can remain in the flue during zeroingSet contents:• testo 330-2 LL flue gas analyzer incl. rechargeable battery and calibration protocol• 100-240 V mains unit for mains operation or charging the rechargeable battery in the instrument• Modular flue gas probe, immersion depth 300 mm, ø 8 mm• CO multi-hole probe shaft suitable for modular flue gas probe• Combustion air temperature probe, immersion depth 190 mm• Hose connection set for separate gas pressure measurement• Flexible probe shaft length 330 mm Dual wall clearance probe• Basic system case for instrument, probes and accessories
